KuWFi 1200Mbps Outdoor AP Repeater Router 2.4G 5.8G Dual Band WiFi Signal Detachable Antenna 24V POE WAN LAN IP65 Waterproof

Tips: The product is AP Router , not support insert 4G USIM Card.

Product Description:

KuWFi AP1200F is an entry-level dual-frequency 802.11ac outdoor wireless access point product, providing 2.4GHz and 5.8GHz dual-frequency wireless services, 2.4GHz up to 300Mbps access rate, 5GHz up to 866Mbps access rate.

Product Features:

1200Mbps Dual Band AP Router:

Providing 2.4GHz and 5.8GHz dual-frequency wireless services, 2.4GHz up to 300Mbps access rate, 5GHz up to 866Mbps access rate.

Support Three Modes:

①AP Mode:
Devices cover wireless network signals over other clients and devices, and use Ethernet to connect to other routers for WAN access

②Gateway Mode:
The device is connected to the WAN network through the WAN port and connected to the Internet using static IP, DHCP or PPPOE

Two External Antennas:

2*5dbi external antennas providing even better wireless performance, transmission rates, stability technology automatically avoids channel conflicts using its channel selection feature.

Outdoor IP65 Waterproof:

Outdoor IP65 waterproof design,Weatherproof enclosure and lightning protection ensure safety and stable connection in harsh outdoor conditions

Two Power Supply Modes:

The AP Router support 24V POE power supply and DC 12V power supply(Package not include DC Power).To meet the needs of different customer need.

Product Specification:

Produt Model: AP1200F
CPU: MT7628DAN+ MT7613BEN
Flash: 8MB
External dual-frequency antenna: 2.4GHz / 5GHz omnidirectional antennas
Antenna gain: 5dBi
2.4GHz Working Frequency Band: 2.4GHz to 2.484GHz
2.4GHz WIFI transmission protocol: 802.11 b/g/n
5GHz Working Frequency Band: 5.150GHz to 5.850GHz
5GHz WIFI transmission protocol: 802.11 a/n/ac

Working Mode:AP Mode,Repeater Mode,Gateway Mode
WAN Port: 10/100Mbps,Support 24V POE
LAN Port: 10/100Mbps
Normal Operating Temperature: -30°C to 55°C
Storage Temperature: -40°C to 70°C
Humidity: 5%~95% (no condensation)

Package Listing:

1x AP Router
1x 24V POE Power Supply
1x Network Cable
1x User Manual
2x Nylon Cable Tie
